PlateSnap Surron Ultra Bee 2023-2025

Here's how it works:
Select your motorcycle model and decide whether you want to add the license plate holder with integrated taillight (including license plate illumination and E-number ) or LED indicators ( E-number ).

Easy installation:
For the Ultra Bee, mounting the license plate holder requires drilling through the rear plastic body. Simply remove the rear plastic body and position the holder as shown in the following photo. (Important: Position it as far back as possible; otherwise, with a soft suspension setup, the license plate may touch the tire during heavy compression.)

Next, the screw points must be marked with a pen or screwdriver so that the holes can then be drilled there (5mm hole).

The bracket is then attached with three screws and locknuts with washers. (NOT included; any standard screws can be used. We recommend screws with an M5 thread.)

Off-road driving:

When you're not riding on the road, we recommend removing the license plate. If the suspension is too soft or under extreme stress, the license plate may come into contact with the rear wheel. This usually won't damage the PlateSnap holder, but it can damage the license plate.

Innovative design:

The license plate is securely mounted to the motorcycle using an action camera rail, secured with a cotter pin, and can be easily removed. This offers you:

• Perfect optics for photos or events.
• More flexibility when off-road driving .
• A creative way to mount an action cam and film your adventures from completely new perspectives.

PlateSnap locking pin:

The PlateSnap locking pin provides additional security for the license plate on the motorcycle. We recommend having the pin installed on every ride.

PlateSnap Safety Screw:

The M5 screw allows you to modify the license plate holder so that it is no longer removable. So, if you're concerned about the appearance of the license plate holder but don't want a removable license plate, you can simply screw it in place with this screw.

Scope of delivery:

• 1x PlateSnap license plate holder
• 1x plate with action cam mount and reflector ( E-number )
• 1x PlateSnap locking pin

Important instructions:

When converting to LED indicators, a load-independent indicator relay is usually necessary; you can find one here , for example.

Legal notice
According to current German legislation, our PlateSnap license plate holders do not require ABE (General Operating Permit) or E-marking. However, legal regulations must be observed during installation (e.g., turn signal spacing, viewing angle, reflector requirements, etc.).

The proper installation and compliance with all road traffic regulations is solely the responsibility of the buyer or vehicle owner.

We accept no liability for damages, fines or accidents resulting from improper installation, misuse or use contrary to the German Road Traffic Regulations (StVZO).

To ensure compliance with the minimum distance for turn signals prescribed in Germany, we recommend our optionally available turn signal extensions .

The optional taillight and optional turn signals are equipped with "Japanese plugs"!

Rear light cable length: approx. 40cm

Turn signal cable length: approx. 30cm
